We have 40 years of literature, documents, wiring diagrams, and manuals on Florida Heat Pump/Bosch geothermal units. We will try to add as much as possible to this website. In the mean time, if you don't see it below, call or email us, maybe we can help by looking it up (you know, the old fashioned way...).
Florida Heat Pump FHP Geothermal Heat Pump Model
Archival Documents for old discontinued models
(FHP Geothermal Heat Pump Installation Manuals and Specifications)
Documents listed alphabetically by model. Go to the bottom of this page for old parts lists and other miscellaneous documents.
FHP Geothermal AP Model (Discontinued 2013)
Stages: 2 // Sizes: 2 thru 6 ton // Configurations: H,V,CF,Splits // R410a
>AP Model Brochure - click here
>AP Promotional Flyer - click here
>AP Model Specifications, Dimensions, Performance - click here
>AP Model Installation, Wiring (1/2012) - click here
>AP Model SPLIT Unit Installation, Wiring - click here
>AP Model SPLIT Unit dimensions - click here
Bosch/FHP Geothermal AU Model (Discontinued)
Stages: 2 // Sizes: 2 thru 6 ton // Configurations: H,V,CF,Splits // R410a
>AU Model Technical Specifications/Dimensions/Performance Data - click here
>AU Model SPLIT Dimensions (see pg 16-18) - click here
>AU Installation Manual - click here
Bosch/FHP Geothermal BP Model (current model) - click here for info & documents
Bosch/FHP Geothermal BC Model - Residential Console Unit - (discontinued 2018)
Stages: 1 // Sizes: .75, 1, 1.25. 1.5 ton // Configurations: Console // R410a // Warranty: 5 yrs on compressor, 1 yr on other parts // Tax Credit: Not Qualified
>BC Model Installation Manual - (4/2016) - click here
>BC Model Marketing Flyer (8/2016) - click here
>BC Model Engineering Submittal (03/2017) - click here
Bosch/FHP Geothermal CA Model - Commercial Console Unit - (current model) click here for info and documents
Bosch/FHP Geothermal CE Model (current model) - click here for info & documents
CE Splits: The CE model was manufactured in a split configuration until 2014. From 2014 thru 2018 Bosch made the CE condensing section, but not the CE air handler. In 2019 Bosch discontinued the CE condensing section. Bosch continues to make the CE vertical, horizontal, and counterflow package units. Click above to redirect to the Bosch page on the CE model. Below are the discontinued CE split documents.
CE SPLIT Dimensions/Performance (3/2011) - click here
CE SPLIT Installation & Wiring (3/2011) - click here
Bosch/FHP Geothermal CP Model (Discontinued 2013)
Stages: 1 // Sizes: 2 thru 6 ton, with half ton sizes // Configurations: H,V // R410a // Warranty: 10 yrs // Tax Credit: Qualified
>CP Model Brochure - click here
>CP Model Specifications, Dimensions, Performance (3/2012) - click here
>CP Model Installation, Wiring (5/2012) - click here
Bosch/FHP Geothermal CS Model - Console Unit (Discontinued 2019)
Stages: 1 // Sizes: 3/4 thru 1.5 ton (CS009, CS012, CS015, CS018) // Configuration: Console // R22
> CS Model Installation Guide (2008) - click here
> CS Model Specs and Performance (2008) - click here
FHP Geothermal EC* Model (.5 ton thru 6 ton sizes Discontinued 2013)
Stages: 1 // Sizes: .5 thru 6 ton, with half ton sizes // Configurations: H,V,CF, Splits // R410a
>EC Model Installation, Wiring (5/2012) - click here
>EC Model Installation, Wiring 2004 version - click here
>EC Model Brochure (includes dimensions, options, wiring, & specifications (10/2012) - click here
>EC Model Flyer (4/2012) - click here
>EC Model SPLIT Install (this is a general installation manual for split units) - click here
>EC Model Specifications, Performance (6/2004) - click here
* Just the smaller size EC model was discontinued - EC007 (.5 ton) through EC070 (6 ton). As of 7/1/2016, the EC model in the 7 through 30 tons sizes were still in production.
FHP Geothermal EM Model (Discontinued)
Stages: 1 // Sizes: 2 thru 6 ton, with half ton sizes // Configurations: H,V,CF,Splits // R22
>EM Model Specifications, Dimensions, Performance - click here
>EM Model Installation, Wiring - click here
>EM Split Installation - click here
>EM Split dimensions - click here
Bosch/FHP Geothermal EP Model (current model) - click here for info & documents
FHP Geothermal ES* (single stage) Model (Discontinued 2013)
Stages: 1 // Sizes: 1.5 thru 6 ton, with half ton sizes // Configurations: H,V // R410a
>ES Model Brochure (includes dimensions, options, wiring, and specifications) (10/2012) - click here
>ES Model Specifications, Performance (10/2006) - click here
>ES Installation Manual - click here
* Just the single stage ES model has been discontinued (ES018, 024, 030, 036, 042, 048, 060, 070). The ES2, a two-stage geothermal unit (ES025, 035, 049, 061, 071), is still in production and can be found under the Products/Commercial page. Or click here.
FHP Geothermal EV Model (Discontinued)
Stages: 1 // Sizes: 1.5 thru 6 ton, with half ton sizes // Configurations: H,V,CF,Splits // R410a
>EV Model Brochure - click here
>EV Model Specifications, Dimensions, Performance - click here
>EV Model Installation, Wiring - click here
>EV Split Installation (this is a general installation manual for split units)- click here
>EV Split Dimensions - click here
Genesis Control/Fan Board Manual & Blink Codes - click here
These boards were installed in many of the FHP SX and GO model geothermal units during the mid to late 1990's. These boards are no longer made.
>SX/GO Electrical Box Removal Instructions - click here
>SX/GO Genesis Board Replacement Wiring Diagram - Single Stage/Phase units - click here
FHP Geothermal GO Model (1996, Discontinued 2003)
Stages: 1 (4 & 5 ton were multi-step) // Sizes: .5 thru 6 ton, with half ton sizes // Configurations: H,V,CF // R22
>GO Model Specifications, Dimensions, Performance (1998) - click here
>GO Model Installation, Wiring - click here
>GO Dimensions - go to the Unit Dimension Cross Reference - click here, scroll down
>GO Genesis VI Control Board Engineering Application Manual - click here
>SX/GO Electrical Box Removal Instructions - click here
>SX/GO Genesis Board Replacement Wiring Diagram - Single Stage/Phase units - click here
FHP Geothermal GS Model (1996, Discontinued 2008)
Stages: 1 // Sizes: 2 thru 6 ton, with half ton sizes // Configurations: H,V,CF, splits // R22
>GS Model Specifications, Dimensions, Performance (2006) - click here
>GS Model Installation & wiring (4/2008) - click here
>GS Wiring without electric heat - click here
>GS wiring with electric heat - click here
>GS Split Installation (generic) - click here
>GS Split dimensions (pages 8 - 11) - click here
FHP Geothermal GT Model (1996, Discontinued 2008)
Stages: 1 // Sizes: 2 thru 6 ton, with half ton sizes // Configurations: H,V,CF,Splits // R22
>GT Model Specifications, Dimensions, Performance - click here
>GT Model Installation - click here
>GT Wiring without electric heat - click here
>GT wiring with electric heat - click here
>GT Split Installation (generic) - click here
>GT Split dimensions (pages 8 - 11) - click here
FHP Geothermal HE Model (1996, Discontinued 2008)
Stages: 1 // Sizes: 2 thru 6 ton, with half ton sizes // Configurations: H,V,CF, splits // R22
>HE Model Installation (12/1994) - click here (Note: document scanned backwards, start at the end for pg 1)
>HE Split Install Supplement - included base charge amount - click here
>HE Operating Pressures & Temperatures - click here
>HE Specification Guide and Specifications on HE007, HE009, HE012, HE015, HE019 - click here (doc scanned backwards, start at end for pg 1)
>HE Specifications on HE023, HE027, HE031, HE034, HE036, HE040, HE041, HE042, HE048 - click here
>HE Specifications on HE052, HE062, HE070, HE084, HE094, HE095, HE104 - click here
>HE Specifications on HE121, HE122, HE140, HE150, HE170, HE214 - click here
>HE Wiring diagram on package unit, single phase - models HE007 thru HE080 1992 - click here
>HE Wiring Diagram on split units, single phase - models HE007 thru HE080 1992 - click here
Bosch/FHP Geothermal LM Model (current model) - click here for info & documents
FHP Geothermal LT Model (Discontinued)
Stages: 1 (hybrid, Lo-Temp Series) // Sizes: .75 thru 7.5 ton, with half ton sizes // Configurations: H,V,CF // R22
> LT Specifications and Cut Sheet: LT10 / LT15 / LT20 / LT30 / LT40 / LT50 / LT60 / LT70 / LT90
> LT Cooling Performance Ratings - click here
> LT SPLIT Performance - click here
> LT Installation Guide - Supplement - click here
> LT Split Install Supplement - included base charge amount - click here
> LT Wiring diagram on package unit, single phase - models LT010 thru LT090 1991 - click here
> LT 1990 Wiring Diagram for models LT010 thru LT090 - click here
> LT Wiring Diagram on split units, single phase - models LT010 thru LT090 1992 - click here
Bosch/FHP Geothermal LV Model (current model) - click here for info & documents
Stages: 1 // Sizes: .5 thru 6 ton, with half ton sizes // Configurations: H,V // 410a // Introduced in 2014 // Counterflow configuration discontinued 2018 // Splits discontinued in 2019
>LV Engineering Submittal (02/2018) - click here
>LV Engineering Submittal for SPLITS (10/2016) (discontinued) - click here
>LV Brochure - Dimensions & Performance (06/2013) - click here
>LV Brochure - Dimensions & Performance for SPLITS (5/2018) (discontinued) - click here
>Bosch-FHP COMMERCIAL Warranty & Terms (4/2014) - click here
>Bosch-FHP Extended Warranty-up to 5 yrs all parts-click here
>Bosch-FHP Extended Warranty-up to 5 yrs parts & labor-click here
>LV Package units Installation/Wiring Manual (4/2013) - click here
>LV SPLIT Installation - condensing section (1/2015) (discontinued) - click here
>LV SPLIT Air Handler Installation Manual (1/2015) (discontinued) - click here
FHP Geothermal SE Model (Discontinued)
Stages: 1 (Super Efficiency Series) // Sizes: 2 thru 5 ton, with some half ton sizes // Configurations: H,V,CF // R22
>SE Installation Guide - click here (Note: document scanned backwards, start at the end for pg 1)
>SE Split Install Supplement - included base charge amount - click here
>SE Specification Guide (the 1st page is blank; page-up) - click here
>SE specifications : SE022 / SE026 / SE032 / SE038 / SE046 / SE053 / SE063
>SE Wiring diagram on package unit, single phase - models SE022 thru SE063 1992 - click here
>SE Wiring Diagram on split units, single phase - models SE022 thru SE063 1992 - click here
FHP Geothermal SL Model (Discontinued - *see note)
Stages: 1 (Super Lo-Temp Series) // Sizes: 1.5 thru 3.5 ton, with half ton sizes // Configurations: H,V,CF // R22
>SL Specification Guide - click here
>SL specifications : SL010 / SL016 / SL020 / SL025 / SL030 / SL040 / SL065 / SL080 Horizontal / SL080 Vertical
>SL specifications: SL045, SL050, SL055 - Click here
>Genesis VI Engineering Application Manual - click here
>SL Split Install Supplement - included base charge amount - click here
>SL Wiring diagram on package unit, single phase - models SL010 thru SL065 1991 - click here
>SL 1990 Wiring Diagram for SL20, SL25, SL30, SL40 - click here
>SL Wiring Diagram on split units, single phase - models SL010 thru SL065 1992 - click here
* The SL model to which the above literature refers is for a residential geothermal unit manufactured during the 1990's.
From approximately 2014 thru 7/2018 Bosch produced a light commercial SL model in 6, 8, and 10 ton sizes.
>SL Engineering Submittal (06/2014) - click sl_engineering_submittal_sheet_06_2014_us.pdf here
>SL Marketing Flyer (10/2014) - click sl_flyer_2015.pdf here
Bosch/FHP Geothermal SM Model (2013-current model) - click here for info & documents
Bosch/FHP Geothermal SV Model (current model) - click here for info & documents
This is a current model still in production at the Florida plant. For the most up-to-date documents please refer to the Bosch website: Click here
Stages: 1 // Sizes: .5 thru 6 ton, with half ton sizes // Configurations: H,V,CF, splits // 410a // Introduced in 2014 // Counterflow configuration discontinued 2018 // Splits discontinued in 2019
>SV Engineering Submittal (11/2013) - click here
>SV Engineering Submittal for SPLITS (5/2014) - click here
>SV Brochure - Dimensions & Performance (09/2013) - click here
>SV Brochure - Dimensions & Performance for SPLITS (6/2014) - click here
>Bosch-FHP COMMERCIAL Warranty & Terms (4/2014) - click here
>Bosch-FHP Extended Warranty-up to 5 yrs all parts-click here
>Bosch-FHP Extended Warranty-up to 5 yrs parts & labor-click here
>SV Package units Installation/Wiring Manual (8/2013) - click here
>SV SPLIT Installation - condensing section (12/2015) - click here
>SV SPLIT Air Handler Installation Manual (01/2015) - click here
>SV Vertical Dimensions (11/2013) - click here
>SV Horizontal Dimensions (11/2013) - click here
>SV Counterflow Dimensions (11/2013) - click here
FHP Geothermal SX Model (1992, Discontinued 1997)
Stages: 1 <3.5ton 2 stage >4ton // Sizes: 2 thru 6 ton, with half ton sizes // Configurations: H,V,CF, splits // R22
>SX Model Installation - click here
>SX Specifications (performance & cut sheets) Models: SX024/SX030/SX036/SX042 - click here (single stage compressors)
>SX Specifications (performance & cut) Model: SX048 // Model: SX060 // Model: SX072 (two stage compressors)
>SX wiring with electric heat - click here
>SX Electrical Box Removal Instructions - click here
>SX Genesis VI Control Board Engineering Application Manual - click here
>SX/GO Genesis Board Replacement Wiring Diagram - Single Stage/Phase units - click here
Bosch/FHP Geothermal TA Model (Discontinued 2013)
Stages: 2 // Sizes: 2 thru 6 ton // Configurations: H,V,CF,Splits // R410a // Warranty: 10 yrs // Tax Credit: Qualified
>TA Technical Specifications/Dimensions/Performance Data - click here
>TA Installation and Maintenance Manual for PACKAGE Units - click here
>TA Installation and Maintenance Manual for SPLIT Units - click here
Bosch/FHP Geothermal TW Model (current model) - click here for info & documents
FHP Geothermal WH Model (Discontinued when 410a refrigerant came into use)
Stages: 1 // Sizes: ? 1.5 ton // Configurations: water2water condensing section // R410a // discontinued
This model was a water-to-water unit designed for heating domestic hot water.
>WH018 Technical Specifications/Dimensions/Performance Data - click here
Bosch/FHP Geothermal WT Model (current model) - click here for info & documents
Archival Documents for old discontinued models
(FHP Geothermal Heat Pump Installation Manuals and Specifications)
Documents listed alphabetically by model. Go to the bottom of this page for old parts lists and other miscellaneous documents.
FHP Geothermal AP Model (Discontinued 2013)
Stages: 2 // Sizes: 2 thru 6 ton // Configurations: H,V,CF,Splits // R410a
>AP Model Brochure - click here
>AP Promotional Flyer - click here
>AP Model Specifications, Dimensions, Performance - click here
>AP Model Installation, Wiring (1/2012) - click here
>AP Model SPLIT Unit Installation, Wiring - click here
>AP Model SPLIT Unit dimensions - click here
Bosch/FHP Geothermal AU Model (Discontinued)
Stages: 2 // Sizes: 2 thru 6 ton // Configurations: H,V,CF,Splits // R410a
>AU Model Technical Specifications/Dimensions/Performance Data - click here
>AU Model SPLIT Dimensions (see pg 16-18) - click here
>AU Installation Manual - click here
Bosch/FHP Geothermal BP Model (current model) - click here for info & documents
Bosch/FHP Geothermal BC Model - Residential Console Unit - (discontinued 2018)
Stages: 1 // Sizes: .75, 1, 1.25. 1.5 ton // Configurations: Console // R410a // Warranty: 5 yrs on compressor, 1 yr on other parts // Tax Credit: Not Qualified
>BC Model Installation Manual - (4/2016) - click here
>BC Model Marketing Flyer (8/2016) - click here
>BC Model Engineering Submittal (03/2017) - click here
Bosch/FHP Geothermal CA Model - Commercial Console Unit - (current model) click here for info and documents
Bosch/FHP Geothermal CE Model (current model) - click here for info & documents
CE Splits: The CE model was manufactured in a split configuration until 2014. From 2014 thru 2018 Bosch made the CE condensing section, but not the CE air handler. In 2019 Bosch discontinued the CE condensing section. Bosch continues to make the CE vertical, horizontal, and counterflow package units. Click above to redirect to the Bosch page on the CE model. Below are the discontinued CE split documents.
CE SPLIT Dimensions/Performance (3/2011) - click here
CE SPLIT Installation & Wiring (3/2011) - click here
Bosch/FHP Geothermal CP Model (Discontinued 2013)
Stages: 1 // Sizes: 2 thru 6 ton, with half ton sizes // Configurations: H,V // R410a // Warranty: 10 yrs // Tax Credit: Qualified
>CP Model Brochure - click here
>CP Model Specifications, Dimensions, Performance (3/2012) - click here
>CP Model Installation, Wiring (5/2012) - click here
Bosch/FHP Geothermal CS Model - Console Unit (Discontinued 2019)
Stages: 1 // Sizes: 3/4 thru 1.5 ton (CS009, CS012, CS015, CS018) // Configuration: Console // R22
> CS Model Installation Guide (2008) - click here
> CS Model Specs and Performance (2008) - click here
FHP Geothermal EC* Model (.5 ton thru 6 ton sizes Discontinued 2013)
Stages: 1 // Sizes: .5 thru 6 ton, with half ton sizes // Configurations: H,V,CF, Splits // R410a
>EC Model Installation, Wiring (5/2012) - click here
>EC Model Installation, Wiring 2004 version - click here
>EC Model Brochure (includes dimensions, options, wiring, & specifications (10/2012) - click here
>EC Model Flyer (4/2012) - click here
>EC Model SPLIT Install (this is a general installation manual for split units) - click here
>EC Model Specifications, Performance (6/2004) - click here
* Just the smaller size EC model was discontinued - EC007 (.5 ton) through EC070 (6 ton). As of 7/1/2016, the EC model in the 7 through 30 tons sizes were still in production.
FHP Geothermal EM Model (Discontinued)
Stages: 1 // Sizes: 2 thru 6 ton, with half ton sizes // Configurations: H,V,CF,Splits // R22
>EM Model Specifications, Dimensions, Performance - click here
>EM Model Installation, Wiring - click here
>EM Split Installation - click here
>EM Split dimensions - click here
Bosch/FHP Geothermal EP Model (current model) - click here for info & documents
FHP Geothermal ES* (single stage) Model (Discontinued 2013)
Stages: 1 // Sizes: 1.5 thru 6 ton, with half ton sizes // Configurations: H,V // R410a
>ES Model Brochure (includes dimensions, options, wiring, and specifications) (10/2012) - click here
>ES Model Specifications, Performance (10/2006) - click here
>ES Installation Manual - click here
* Just the single stage ES model has been discontinued (ES018, 024, 030, 036, 042, 048, 060, 070). The ES2, a two-stage geothermal unit (ES025, 035, 049, 061, 071), is still in production and can be found under the Products/Commercial page. Or click here.
FHP Geothermal EV Model (Discontinued)
Stages: 1 // Sizes: 1.5 thru 6 ton, with half ton sizes // Configurations: H,V,CF,Splits // R410a
>EV Model Brochure - click here
>EV Model Specifications, Dimensions, Performance - click here
>EV Model Installation, Wiring - click here
>EV Split Installation (this is a general installation manual for split units)- click here
>EV Split Dimensions - click here
Genesis Control/Fan Board Manual & Blink Codes - click here
These boards were installed in many of the FHP SX and GO model geothermal units during the mid to late 1990's. These boards are no longer made.
>SX/GO Electrical Box Removal Instructions - click here
>SX/GO Genesis Board Replacement Wiring Diagram - Single Stage/Phase units - click here
FHP Geothermal GO Model (1996, Discontinued 2003)
Stages: 1 (4 & 5 ton were multi-step) // Sizes: .5 thru 6 ton, with half ton sizes // Configurations: H,V,CF // R22
>GO Model Specifications, Dimensions, Performance (1998) - click here
>GO Model Installation, Wiring - click here
>GO Dimensions - go to the Unit Dimension Cross Reference - click here, scroll down
>GO Genesis VI Control Board Engineering Application Manual - click here
>SX/GO Electrical Box Removal Instructions - click here
>SX/GO Genesis Board Replacement Wiring Diagram - Single Stage/Phase units - click here
FHP Geothermal GS Model (1996, Discontinued 2008)
Stages: 1 // Sizes: 2 thru 6 ton, with half ton sizes // Configurations: H,V,CF, splits // R22
>GS Model Specifications, Dimensions, Performance (2006) - click here
>GS Model Installation & wiring (4/2008) - click here
>GS Wiring without electric heat - click here
>GS wiring with electric heat - click here
>GS Split Installation (generic) - click here
>GS Split dimensions (pages 8 - 11) - click here
FHP Geothermal GT Model (1996, Discontinued 2008)
Stages: 1 // Sizes: 2 thru 6 ton, with half ton sizes // Configurations: H,V,CF,Splits // R22
>GT Model Specifications, Dimensions, Performance - click here
>GT Model Installation - click here
>GT Wiring without electric heat - click here
>GT wiring with electric heat - click here
>GT Split Installation (generic) - click here
>GT Split dimensions (pages 8 - 11) - click here
FHP Geothermal HE Model (1996, Discontinued 2008)
Stages: 1 // Sizes: 2 thru 6 ton, with half ton sizes // Configurations: H,V,CF, splits // R22
>HE Model Installation (12/1994) - click here (Note: document scanned backwards, start at the end for pg 1)
>HE Split Install Supplement - included base charge amount - click here
>HE Operating Pressures & Temperatures - click here
>HE Specification Guide and Specifications on HE007, HE009, HE012, HE015, HE019 - click here (doc scanned backwards, start at end for pg 1)
>HE Specifications on HE023, HE027, HE031, HE034, HE036, HE040, HE041, HE042, HE048 - click here
>HE Specifications on HE052, HE062, HE070, HE084, HE094, HE095, HE104 - click here
>HE Specifications on HE121, HE122, HE140, HE150, HE170, HE214 - click here
>HE Wiring diagram on package unit, single phase - models HE007 thru HE080 1992 - click here
>HE Wiring Diagram on split units, single phase - models HE007 thru HE080 1992 - click here
Bosch/FHP Geothermal LM Model (current model) - click here for info & documents
FHP Geothermal LT Model (Discontinued)
Stages: 1 (hybrid, Lo-Temp Series) // Sizes: .75 thru 7.5 ton, with half ton sizes // Configurations: H,V,CF // R22
> LT Specifications and Cut Sheet: LT10 / LT15 / LT20 / LT30 / LT40 / LT50 / LT60 / LT70 / LT90
> LT Cooling Performance Ratings - click here
> LT SPLIT Performance - click here
> LT Installation Guide - Supplement - click here
> LT Split Install Supplement - included base charge amount - click here
> LT Wiring diagram on package unit, single phase - models LT010 thru LT090 1991 - click here
> LT 1990 Wiring Diagram for models LT010 thru LT090 - click here
> LT Wiring Diagram on split units, single phase - models LT010 thru LT090 1992 - click here
Bosch/FHP Geothermal LV Model (current model) - click here for info & documents
Stages: 1 // Sizes: .5 thru 6 ton, with half ton sizes // Configurations: H,V // 410a // Introduced in 2014 // Counterflow configuration discontinued 2018 // Splits discontinued in 2019
>LV Engineering Submittal (02/2018) - click here
>LV Engineering Submittal for SPLITS (10/2016) (discontinued) - click here
>LV Brochure - Dimensions & Performance (06/2013) - click here
>LV Brochure - Dimensions & Performance for SPLITS (5/2018) (discontinued) - click here
>Bosch-FHP COMMERCIAL Warranty & Terms (4/2014) - click here
>Bosch-FHP Extended Warranty-up to 5 yrs all parts-click here
>Bosch-FHP Extended Warranty-up to 5 yrs parts & labor-click here
>LV Package units Installation/Wiring Manual (4/2013) - click here
>LV SPLIT Installation - condensing section (1/2015) (discontinued) - click here
>LV SPLIT Air Handler Installation Manual (1/2015) (discontinued) - click here
FHP Geothermal SE Model (Discontinued)
Stages: 1 (Super Efficiency Series) // Sizes: 2 thru 5 ton, with some half ton sizes // Configurations: H,V,CF // R22
>SE Installation Guide - click here (Note: document scanned backwards, start at the end for pg 1)
>SE Split Install Supplement - included base charge amount - click here
>SE Specification Guide (the 1st page is blank; page-up) - click here
>SE specifications : SE022 / SE026 / SE032 / SE038 / SE046 / SE053 / SE063
>SE Wiring diagram on package unit, single phase - models SE022 thru SE063 1992 - click here
>SE Wiring Diagram on split units, single phase - models SE022 thru SE063 1992 - click here
FHP Geothermal SL Model (Discontinued - *see note)
Stages: 1 (Super Lo-Temp Series) // Sizes: 1.5 thru 3.5 ton, with half ton sizes // Configurations: H,V,CF // R22
>SL Specification Guide - click here
>SL specifications : SL010 / SL016 / SL020 / SL025 / SL030 / SL040 / SL065 / SL080 Horizontal / SL080 Vertical
>SL specifications: SL045, SL050, SL055 - Click here
>Genesis VI Engineering Application Manual - click here
>SL Split Install Supplement - included base charge amount - click here
>SL Wiring diagram on package unit, single phase - models SL010 thru SL065 1991 - click here
>SL 1990 Wiring Diagram for SL20, SL25, SL30, SL40 - click here
>SL Wiring Diagram on split units, single phase - models SL010 thru SL065 1992 - click here
* The SL model to which the above literature refers is for a residential geothermal unit manufactured during the 1990's.
From approximately 2014 thru 7/2018 Bosch produced a light commercial SL model in 6, 8, and 10 ton sizes.
>SL Engineering Submittal (06/2014) - click sl_engineering_submittal_sheet_06_2014_us.pdf here
>SL Marketing Flyer (10/2014) - click sl_flyer_2015.pdf here
Bosch/FHP Geothermal SM Model (2013-current model) - click here for info & documents
Bosch/FHP Geothermal SV Model (current model) - click here for info & documents
This is a current model still in production at the Florida plant. For the most up-to-date documents please refer to the Bosch website: Click here
Stages: 1 // Sizes: .5 thru 6 ton, with half ton sizes // Configurations: H,V,CF, splits // 410a // Introduced in 2014 // Counterflow configuration discontinued 2018 // Splits discontinued in 2019
>SV Engineering Submittal (11/2013) - click here
>SV Engineering Submittal for SPLITS (5/2014) - click here
>SV Brochure - Dimensions & Performance (09/2013) - click here
>SV Brochure - Dimensions & Performance for SPLITS (6/2014) - click here
>Bosch-FHP COMMERCIAL Warranty & Terms (4/2014) - click here
>Bosch-FHP Extended Warranty-up to 5 yrs all parts-click here
>Bosch-FHP Extended Warranty-up to 5 yrs parts & labor-click here
>SV Package units Installation/Wiring Manual (8/2013) - click here
>SV SPLIT Installation - condensing section (12/2015) - click here
>SV SPLIT Air Handler Installation Manual (01/2015) - click here
>SV Vertical Dimensions (11/2013) - click here
>SV Horizontal Dimensions (11/2013) - click here
>SV Counterflow Dimensions (11/2013) - click here
FHP Geothermal SX Model (1992, Discontinued 1997)
Stages: 1 <3.5ton 2 stage >4ton // Sizes: 2 thru 6 ton, with half ton sizes // Configurations: H,V,CF, splits // R22
>SX Model Installation - click here
>SX Specifications (performance & cut sheets) Models: SX024/SX030/SX036/SX042 - click here (single stage compressors)
>SX Specifications (performance & cut) Model: SX048 // Model: SX060 // Model: SX072 (two stage compressors)
>SX wiring with electric heat - click here
>SX Electrical Box Removal Instructions - click here
>SX Genesis VI Control Board Engineering Application Manual - click here
>SX/GO Genesis Board Replacement Wiring Diagram - Single Stage/Phase units - click here
Bosch/FHP Geothermal TA Model (Discontinued 2013)
Stages: 2 // Sizes: 2 thru 6 ton // Configurations: H,V,CF,Splits // R410a // Warranty: 10 yrs // Tax Credit: Qualified
>TA Technical Specifications/Dimensions/Performance Data - click here
>TA Installation and Maintenance Manual for PACKAGE Units - click here
>TA Installation and Maintenance Manual for SPLIT Units - click here
Bosch/FHP Geothermal TW Model (current model) - click here for info & documents
FHP Geothermal WH Model (Discontinued when 410a refrigerant came into use)
Stages: 1 // Sizes: ? 1.5 ton // Configurations: water2water condensing section // R410a // discontinued
This model was a water-to-water unit designed for heating domestic hot water.
>WH018 Technical Specifications/Dimensions/Performance Data - click here
Bosch/FHP Geothermal WT Model (current model) - click here for info & documents
Old FHP Geothermal Heat Pump Parts list:
These are old, old parts lists for FHP geothermal heat pumps. Pay no attention to the prices. And, all the part/item numbers are out of date as well, but there may be some useful information.
2002 - click here
2006 - click here
2008 - click here
Looking to purchase replacement parts? Call us, and have the model and serial number handy.
Typical Open Loop Plumbing Diagram (hand-drawn) - click here
Diagram for Acid Cleaning of a Water Coil - click here
Miscellaneous FHP/Bosch Geothermal Heat Pump Wiring Diagrams:
> Wiring Diagram - Package units - 3 phase - models: HE031-062, SE053-063, (1992) - click here
> Wiring Diagram - Package units - 3 phase - models: HE080-120, LT090 (1991) - click here
> Wiring Diagram - Package units - 3 phase - models: LT040-070, SL055-065 (1992) - click here
> Wiring Diagram - Split units - 3 phase - models: HE031-062, SE053-063, LT040-070, SL055-065, (1991) - click here
> Wiring Diagram - Split units - 3 phase - models: HE080-120, LT090 (1992) - click here
Diagram for Acid Cleaning of a Water Coil - click here
Miscellaneous FHP/Bosch Geothermal Heat Pump Wiring Diagrams:
> Wiring Diagram - Package units - 3 phase - models: HE031-062, SE053-063, (1992) - click here
> Wiring Diagram - Package units - 3 phase - models: HE080-120, LT090 (1991) - click here
> Wiring Diagram - Package units - 3 phase - models: LT040-070, SL055-065 (1992) - click here
> Wiring Diagram - Split units - 3 phase - models: HE031-062, SE053-063, LT040-070, SL055-065, (1991) - click here
> Wiring Diagram - Split units - 3 phase - models: HE080-120, LT090 (1992) - click here
